Machine Capacities List

Conventional EDM

Machine Steel Size C-Axis CNC Orbit Tipped Head
Mitsubishi EX22 38 x 28
Mitsubishi EX22 38 x 28
Mitsubishi EA30 57 x 37
Mitsubishi EX30 57 x 37
Mitsubishi EX30 48 x 33
Mitsubishi EX8 18 x 24
Shulson Double Header 50 x Unlimited
Large Conventional x 5 60 x Unlimited

Wire EDM

Machine Tank Size Cutting Area Z Height UV Travel
Mitsubishi FX-30 52 x 41.5 29.3 X 19.2 17.875 2.9"
Mitsubishi FX-20K x 3 41.3 x 31.5 19.6 x 13.7 11.750 1.000"
Mitsubishi FX-20K x 3 41.3 x 31.5 19.6 x 13.7 11.750 1.278"
Mitsubishi FX-20 41.3 x 31.5 19.6 x 13.7 11.750 1.300"
Mitsubishi CX-20 28 x 36 19.6 x 13.7 11.750 2.000"
Mitsubishi FA-20 32.75 x 41.9 15.75 x 23.575 11.750 2.9"
Mitsubishi FX-10 x 2 31 x 51 13.800 x 9.000 8.800 1.400"
Mitsubishi FA-10 24 x 32 13.790 x 9.860 8.744 1.280"
Mitsubishi MV-2400 32.75 x 41.9 15.7 x 23.575 16.8 2.995"
Mitsubishi MV-12 33 x 30 15.7 x 11.8 8.7 2.4"
Mitsubishi 200H 38 x Unlimited 15.7 x 29.5 11.5 1.0"
Mitsubishi 400HA 63 x Unlimited 31.5 x 39.5 18 1.0"

Fast Hole

Machine Part Size Work Area Mach Z Hole Size
Aztec CDH-3A 24 x 36 12 x 12 9 .3 - 3.0 mm
Aztec A33M 24 x 36 12 x 12 12 .3 3.0 mm
Aztec Aztec CDH-2A 24 x 36 10 x 6 24 .3 - 3.0 mm
Belmont - Maxsee 12 x 6 10 x 6 12 .3 - 3.0 mm

CNC Milling

Machine Weight Limits
Roku-Roku HC-548EX 400 X-18   Y-14   Z-10
High Speed Brute x 2 2500 X-21.5   Y-12   Z-17
Fadal 3016 15,000 RPM 3000 X-20   Y-16   Z-20
Makino SNC 64 X-20   Y-15   Z-13
OKK DGM 400 X-22   Y-15   Z-16
OKK 64 X-15   Y-12   Z-12
